China Grade 2 finished hexagon nuts Manufacturer, Supplier, Factory
When it comes to securing your assemblies with reliability and precision, our high-quality finished hexagon nuts are the industry benchmark. Engineered to meet rigorous standards, these components are essential for countless applications across various sectors. As a fundamental type of fastener, hexagon nuts provide a robust and easily serviceable connection. Our finished hexagon nuts undergo a thorough finishing process, ensuring a smooth surface, consistent threads, and superior corrosion resistance. This makes them an ideal choice for both standard and demanding environments where vibration resistance and long-term integrity are paramount.
The Grade 2 finished hexagon nuts are manufactured from low carbon steel, providing a dependable balance of strength and ductility for a wide range of general-purpose applications. This product is characterized by its specific mechanical properties and dimensional accuracy, ensuring a perfect fit and reliable performance with matching bolts. Below are the detailed specifications and parameters that define the Grade 2 finished hexagon nuts.
Key Features of Grade 2 Finished Hexagon Nuts
- Material: Low Carbon Steel
- Grade: 2
- Finish: Plain, Zinc Plated, or other finishes upon request
- Threads: UNC (Unified National Coarse) or UNF (Unified National Fine)
- Standards: Compliant with ASME B18.2.2 and other relevant international standards
- Corrosion Resistance: Suitable for indoor applications; plated options offer enhanced protection.
- Reusability: Designed for multiple installations and removals without significant thread wear.
Detailed Technical Specifications
| Nominal Size (Inches) | Width Across Flats (Inches) | Width Across Corners (Inches) | Height (Inches) | Proof Load (psi) | Typical Applications |
|---|---|---|---|---|---|
| 1/4 | 7/16 | 0.505 | 7/32 | 5,400 | Furniture, light fixtures |
| 5/16 | 1/2 | 0.577 | 17/64 | 5,400 | Automotive components, machinery |
| 3/8 | 9/16 | 0.650 | 21/64 | 5,400 | Structural frameworks, general fabrication |
| 7/16 | 5/8 | 0.722 | 3/8 | 5,400 | Agricultural equipment, trailers |
| 1/2 | 3/4 | 0.866 | 7/16 | 5,400 | Heavy machinery, construction |
Material and Mechanical Properties
| Property | Specification |
|---|---|
| Material Composition | Low Carbon Steel (AISI 1008/1010 equivalent) |
| Hardness (Brinell) | 159 HB Max |
| Tensile Strength | 74,000 psi Min |
| Proof Load Stress | 5,400 psi |
| Operating Temperature Range | -50°F to +250°F (-45°C to +121°C) |
