Home > Products > Hexagon Nut for Side

China Hexagon Nut for Side Manufacturer, Supplier, Factory

Discover high-performance Hexagon Nut for Side solutions engineered for superior fastening in demanding industrial applications. Our product range includes specialized options such as Double Chamfered Hex Nuts that reduce installation stress and improve assembly efficiency, Hexagon Nuts with Height 1.5d offering enhanced thread engagement and load distribution, durable Black Hexagonal Thin Nuts ideal for space-constrained assemblies with corrosion-resistant finishes, and robust Black Heaye Hexagon Nut variants designed for heavy-duty mechanical systems requiring maximum torque resistance.


The Hexagon Nut for Side is precision-manufactured to meet international standards, featuring optimal dimensional accuracy and material properties for reliable performance. Below are the detailed specifications presented in both list and table formats for clear technical reference.

Key Product Parameters

  • Material Grade: Carbon Steel Grade 8, Stainless Steel 304/316, Alloy Steel
  • Surface Treatment: Zinc Plated, Hot-Dip Galvanized, Black Oxide, Dichromate
  • Thread Type: Metric Coarse, Metric Fine, UNC, UNF
  • Hardness: 70-95 HRB (Carbon Steel), 80-100 HRB (Stainless Steel)
  • Temperature Range: -40°C to +120°C (Standard), up to +300°C (High-Temp Variants)
  • Corrosion Resistance: Salt Spray Test 120-500 hours depending on coating

Detailed Technical Specifications

Size (M) Width Across Flats (mm) Height (mm) Thread Pitch (mm) Recommended Torque (Nm)
M6 10 5.0 1.0 9.5
M8 13 6.5 1.25 22
M10 17 8.0 1.5 43
M12 19 10.0 1.75 75
M16 24 13.0 2.0 150
M20 30 16.0 2.5 260

Mechanical Properties Table

Property Carbon Steel Grade 8 Stainless Steel 304 Alloy Steel
Tensile Strength (MPa) 800 min 500 min 1040 min
Proof Load (MPa) 580 310 830
Elongation (%) 12 40 10
Impact Strength (J) 25 55 30
