Transmission Guaranteeing Galvanized Steel Wire

Transmission Guaranteeing Galvanized Steel Wire ensures signal reliability in aerial and direct burial fiber optic cables. As the supplier, Xiaoguo®’s quality assurance includes rigorous salt spray testing for corrosion resistance.

Model:YB/T 098-2011

Send Inquiry

Product Description

In the construction of fiber-to-the-home (FTTH) networks, Transmission Guaranteeing Galvanized Steel Wire are added to the branch cables of the optical cables. This helps to resist tension - whether during the installation of the optical cables or the impact caused by the swaying of trees. These steel wires do not significantly loosen over time, thus maintaining the stability of the optical cables.

Thanks to our large production scale, we have a significant price advantage when providing products to telecom operators. We have a tiered discount system, and orders exceeding 100 tons can enjoy the most favorable discounts.

With our warehouse strategically located adjacent to a core industrial zone, we can achieve dual guarantees: first, ensuring efficient order fulfillment and shortening delivery cycles; second, significantly optimizing transportation costs and reducing overall cooperation costs..

Product Details

In harsh industrial environments such as power plants and factories, the optical cables used for control and data cables require excellent corrosion resistance. Usually, this is achieved by increasing the thickness of the zinc coating.

We not only provide high-quality Transmission Guaranteeing Galvanized Steel Wire at reasonable prices, but also follow up throughout the entire process to ensure that every step of the project goes smoothly. If you are an Original Equipment Manufacturer (OEM) partner, we will provide you with exclusive customized quotes and cooperation discounts to facilitate long-term cooperation between the two parties.

Each batch of products undergoes salt spray testing to evaluate their corrosion resistance. The test results will be included in the material certification package accompanying each batch of goods.

Product Benefits

Hot-dipped galvanizing is our standard for this application, as it provides a thicker, more robust zinc coating that offers superior mechanical protection and a longer lifespan, making it ideal for outdoor Transmission Guaranteeing Galvanized Steel Wire. Electro-galvanizing gives a thinner, smoother coating. For the best balance of corrosion resistance, durability, and cost-effectiveness for aerial and direct burial cables, we strongly recommend the hot-dipped variant.

Diameter	Tolemce	Tehsle strength	Number twist	Number bendin	Zinc weight
mm	mm	min.mpa	min.nt	min.nb	g/㎡
0.40	±0.01	1960	24	9	10-40
0.50	±0.01	1960	24	9	10-40
0.60	±0.01	1960	24	9	10-40
0.70	±0.01	1960	24	9	10-40
0.80	±0.01	1770	27	13	10-40
1.00	±0.02	1670	27	9	10-40
1.20	±0.02	1570	28	15	10-40
1.50	±0.02	1570	27	10	10-40
1.60	±0.03	1570	27	13	10-40
1.70	±0.03	1570	27	12	10-40
2.00	±0.03	1470	25	10	10-40
2.10	±0.03	1470	25	14	10-40
2.20	±0.03	1470	25	13	10-40
2.30	±0.03	1470	23	12	10-40
2.50	±0.03	1470	23	10	10-40
2.60	±0.03	1320	24	10	10-40
