Structurally Sound Galvanized Steel Wire

Structurally Sound Galvanized Steel Wire from supplier Xiaoguo® offers superior corrosion protection for aerial and buried fiber optic cables. Its proper adhesion and compatibility with other components are critical for structural integrity during temperature changes.

Model:YB/T 098-2011

Send Inquiry

Product Description

The Structurally Sound Galvanized Steel Wire is also a key component in self-supporting overhead cables (eight-shaped cables). It is combined with the communication core wire to form a sturdy single-strand wire.

Its Young's modulus is very high, which means that even under continuous tension, it will not elongate significantly. By reducing material waste through advanced galvanizing technology, we are able to translate this cost advantage into the best prices in the industry. If your order exceeds 25 tons, you can enjoy a 5% discount.

This product is packaged with multi-layer special protective paper, which has excellent waterproof and rust-proof properties, ensuring that it is protected from the threats of moisture and rust during transportation and storage, ensuring that the product arrives in the hands of customers intact..

Diameter	Tolemce	Tehsle strength	Number twist	Number bendin	Zinc weight
mm	mm	min.mpa	min.nt	min.nb	g/㎡
0.40	±0.01	1960	24	9	10-40
0.50	±0.01	1960	24	9	10-40
0.60	±0.01	1960	24	9	10-40
0.70	±0.01	1960	24	9	10-40
0.80	±0.01	1770	27	13	10-40
1.00	±0.02	1670	27	9	10-40
1.20	±0.02	1570	28	15	10-40
1.50	±0.02	1570	27	10	10-40
1.60	±0.03	1570	27	13	10-40
1.70	±0.03	1570	27	12	10-40
2.00	±0.03	1470	25	10	10-40
2.10	±0.03	1470	25	14	10-40
2.20	±0.03	1470	25	13	10-40
2.30	±0.03	1470	23	12	10-40
2.50	±0.03	1470	23	10	10-40
2.60	±0.03	1320	24	10	10-40

Product Details

In the interconnection system of the data center, reliability is of utmost importance. Therefore, Structurally Sound Galvanized Steel Wire are used in the indoor/outdoor optical cables. The installation method is exactly the same as the position of the reinforcing components.

These steel wires have a beautiful and neat appearance and are very flexible. Our prices are competitive, making them an economical choice for the expansion of large data centers. We offer free delivery for orders over 30 tons.

We use multiple transportation methods to balance speed and cost. The quality is guaranteed - we adopt statistical process control and conduct final inspections. Additionally, we have certifications such as ISO 9001 and comply with RoHS standards.

FAQ

Q:What is the expected service life of your galvanized steel wire for optical cables in a coastal, high-salinity environment?

A:In coastal environments, our Structurally Sound Galvanized Steel Wire with a heavier Class B or C zinc coating offers superior protection. Zinc plays the role of a sacrificial anode in the system and can effectively slow down the corrosion rate of the base material by preferentially undergoing oxidation reaction. While the exact lifespan depends on specific conditions, our product is engineered to provide decades of service. We can also recommend a Galfan (Zn-5% Al-MM) coated alternative for even greater corrosion resistance in such aggressive saline atmospheres.
