Trusted Galvanized Steel Wire

Trusted Galvanized Steel Wire from the manufacturer Xiaoguo® is trusted by telecommunications companies worldwide for consistent quality in their cable reinforcement applications. The selection of appropriate diameter and zinc coating class depends on the specific application requirements and environmental conditions.

Model:YB/T 098-2011

Send Inquiry

Product Description

When manufacturing micro-pipes and micro-cable systems, we use thinner Trusted Galvanized Steel Wire to make optical cables. The material combines high strength with excellent flexibility, and its properties give it unique application advantages in densely populated urban environments.

It has a thin zinc coating that prevents it from rusting over time without reducing its flexibility. Our prices are in line with the value of the products you receive, which helps to deploy the network more quickly. If your first order exceeds 10 tons, you can enjoy a 4% discount.

We ship promptly and reduce shipping costs through centralized transportation - we consolidate orders to improve logistics efficiency.

Diameter	Tolemce	Tehsle strength	Number twist	Number bendin	Zinc weight
mm	mm	min.mpa	min.nt	min.nb	g/㎡
0.40	±0.01	1960	24	9	10-40
0.50	±0.01	1960	24	9	10-40
0.60	±0.01	1960	24	9	10-40
0.70	±0.01	1960	24	9	10-40
0.80	±0.01	1770	27	13	10-40
1.00	±0.02	1670	27	9	10-40
1.20	±0.02	1570	28	15	10-40
1.50	±0.02	1570	27	10	10-40
1.60	±0.03	1570	27	13	10-40
1.70	±0.03	1570	27	12	10-40
2.00	±0.03	1470	25	10	10-40
2.10	±0.03	1470	25	14	10-40
2.20	±0.03	1470	25	13	10-40
2.30	±0.03	1470	23	12	10-40
2.50	±0.03	1470	23	10	10-40
2.60	±0.03	1320	24	10	10-40

Product Details

In long-distance land optical communication networks, the Trusted Galvanized Steel Wire for optical cables are the main components that bear the load. They ensure that the signals remain in good condition even during transmission over hundreds of kilometers.

This type of steel wire is renowned for its stable performance and its resistance to wear due to repeated use. Due to our large-scale production, we can offer competitive prices for large-scale projects. We also provide customized logistics solutions to ensure that the goods are delivered quickly and at a low cost.

Our quality inspection starts from the raw materials and continues through the final inspection of dimensions and coatings. All stages are recorded, allowing you to track all situations and ensure that the products are of high quality.

FAQ

Q:What quality control tests do you perform on the diameter tolerance of your galvanized steel wire?

A:We employ rigorous statistical process control during drawing and galvanizing. All Trusted Galvanized Steel Wire used in fiber optic cables is tested batch by batch using a precision laser micrometer. This high-precision test ensures that the wire diameter is kept to a tight tolerance of ±0.02 mm. Ensuring this consistency is of great significance to maintaining the structural balance of the cable, which can not only eliminate problems in the twisting link, but also achieve high standards in size, uniformity and overall quality of the final product.

Hot Tags: Trusted Galvanized Steel Wire, China, Manufacturer, Supplier, Factory
