Minimal Stretch Aircraft Steel Wire Rope

Minimal Stretch Aircraft Steel Wire Rope has Xiaoguo®'s technical team, as a supplier, working directly with aviation engineers on application-specific solutions. It's an ultra-high-strength, precision-engineered cable for aviation and aerospace.

Model:YB/T5197-2005

Send Inquiry

Product Description

For each batch of Minimal Stretch Aircraft Steel Wire Rope, we must conduct a comprehensive and documented pre-delivery inspection - this is something that must be done.

This final inspection includes a visual inspection of each wire rope to confirm that all dimensions meet the requirements, and destructive tests are carried out on samples from the production batch. These tests ensure that the wire ropes meet the standards, specifically covering three core dimensions: load-bearing limit before breaking, durability for repeated use, and corrosion resistance.

This process ensures that the wire ropes for aircraft are in compliance with all design and regulatory requirements before delivery. Thus, you will receive clear evidence that the wire ropes are of high quality and safe for use in the aviation sector.

Product Details

We produce aircraft wire ropes. Our production process has been certified by the AS9100 aerospace quality management system - this is a global standard that all enterprises in this industry follow.

In addition, when we produce and test our products, we will adhere to strict standards such as SAE AS71051 and NAS. Every time we ship aircraft wire ropes, we will attach material and product test certificates - such as rolling machine certificates and conformity certificates. These documents enable you to trace every aspect of the product's history and prove its quality, which is also required by the aviation authorities and our customers.

Product Details

Minimal Stretch Aircraft Steel Wire Rope

Diameter mm		Nominal tensile strength	Minimun breaking loa	Approximate weight kg/100m
Nominal diameter	Allowed tolerance	Nominal tensile strength	Minimun breaking loa	Approximate weight kg/100m
6x7+FC
1.8	+100	1960	2.3	1.40
2.15	+80	1960	3.3	2.00
2.5		1960	4.5	2.70
3.05		1870	6.3	4.00
3.6		1870	8.7	5.50
4.1	+70	1770	10.4	7.00
4.5		1770	12.8	8.70
5.4		1670	17.5	12.50
6x7+IWS
1.8	+100	1870	2.5	1.50
2.15	+80		3.6	2.20
2.5			5.0	3.00
3.05			7.3	4.40
3.6			10.1	6.20
4.5	+70	1770	15.0	9.60
5.4	+70	1670	20.4	13.80
6x19+FC
3	+80	2060	6.3	3.80
3.3		1770	6.5	4.50
3.6			7.8	5.40
4.2	+30		10.6	7.4
4.8			12.9	9.00
5.1			15.6	10.90
6.2		1670	20.4	13.80
6x19+IWS
3	+80	2060	7.3	4.2
3.2		2160	8.9	4.30
3.6		1770	9.1	6.00
4.2	+70		12.3	8.20
5.1			18.2	12.10
6		1670	23.7	16.70
7.5	+50		37.1	26.00
8.25			44.9	32.00
9			53.4	37.60
9.75			62.6	44.10

FAQ

Q:What packaging standards do you use for international aviation clients?

A:We pack Minimal Stretch Aircraft Steel Wire Rope on protective reels, sealed in anti-corrosion paper and desiccated packs. Each reel is labeled with part numbers, batch codes, and certifications for full traceability. Our export packaging for Minimal-Stretch Aircraft steel wire rope meets aviation industry requirements, ensuring perfect condition upon arrival at your facility.
