Consistently Reliable Galvanized Steel Wire

Consistently Reliable Galvanized Steel Wire: Xiaoguo®’s factory strictly controls wire rod composition to ensure optimal mechanical properties for downstream processing. Its heavy zinc coating provides superior corrosion resistance, suitable for harsh outdoor environments.

Send Inquiry

Product Description

In prestressed concrete projects, Consistently Reliable Galvanized Steel Wire are used to manufacture steel strands, which are then embedded in concrete components. This enables the concrete to perform better under tension and the steel wires to avoid alkaline corrosion. There is a strong metallurgical bond between the zinc layer of the steel wire and the steel core.

We sell this high-quality product at highly competitive prices. For large infrastructure projects, we offer discounts based on specific projects. The steel wires are placed on heavy-duty reels and wrapped in waterproof packaging. We will arrange for their timely delivery to the construction site.

Our factory has established a complete quality management system to ensure that every roll of steel wire produced strictly complies with the requirements of ASTM A1064 standard.

Product Advantages

When making nails and pins, Consistently Reliable Galvanized Steel Wire is a common choice. This material is easy to shape and the fastened components made from it have excellent corrosion resistance. The surface of this wire has a smooth and uniform coating, which is very suitable for high-speed drawing and forming processes.

Due to our large production volume, we can offer very favorable prices to original equipment manufacturers. If you sign a quarterly contract and the single order quantity exceeds 30 tons, you can enjoy a 3% price discount. It has a bright and shiny appearance, indicating its superior quality.

We guarantee two core points: first, fast delivery without delay and low freight; second, quality inspection will be carried out during production and an inspection report will be provided to ensure that the product performance is stable and there are no problems.

Application Scenario

Consistently Reliable Galvanized Steel Wire is widely used in construction reinforcement, mesh weaving, fencing, and structural applications. Its excellent corrosion resistance makes it an ideal material for applications such as bridge cables, safety fences and agricultural supports. No matter how bad the environment is, galvanized steel wire is not easy to break and is reliable to use; but ordinary steel wire is not the same. It will fail and become unusable after a while.

Consistently Reliable Galvanized Steel Wire

Product parameters table

item	material	(mm) diameter	(mm) tolerance	(Mpa) T/S	/100d torsion	(g/m²) weight of zinc coating
Hot dip galvanized steel wire	60	1.0	+0.03~-0.03	105-125	18	100
	60	1.1	+0.03--0.03	105-125	18	100
	60	1.3	+0.03~-0.03	100-125	18	130
	60	1.4	+0.03~-0.03	100-125	18	140
	60	1.6	+0.04~-0.03	100-125	18	160
	60	1.8	+0.04~-0.03	100-125	17	180
	60	2.0	+0.045~-0.035	100-125	17	210
	60	2.2	+0.045~-0.035	100-120	17	210
	60	2.4	+0.045~-0.035	100-120	17	230
	70	2.6	+0.045~-0.035	110-130	13	240
	70	2.8	+0.045~-0.035	110-130	13	250
	70	3.0	+0.045~-0.035	110-130	13	260
	70	3.2	+0.045~-0.035	108-120	13	260
	70	3.4	+0.045~-0.035	108-120	13	260
	70	3.6	+0.045~-0.035	108-120	13	260
	70	4.0	+0.045~-0.035	105-115	13	260
