Home > Products > Nut > Cap Nut > High Efficiency Hexagon Domed Cap Nuts
      High Efficiency Hexagon Domed Cap Nuts
      • High Efficiency Hexagon Domed Cap NutsHigh Efficiency Hexagon Domed Cap Nuts
      • High Efficiency Hexagon Domed Cap NutsHigh Efficiency Hexagon Domed Cap Nuts
      • High Efficiency Hexagon Domed Cap NutsHigh Efficiency Hexagon Domed Cap Nuts
      • High Efficiency Hexagon Domed Cap NutsHigh Efficiency Hexagon Domed Cap Nuts
      • High Efficiency Hexagon Domed Cap NutsHigh Efficiency Hexagon Domed Cap Nuts

      High Efficiency Hexagon Domed Cap Nuts

      High efficiency hexagon domed cap nuts have a rounded head that won't scratch other items and are commonly used in aerospace, automotive, and structural applications. Xiaoguo® undergoes rigorous testing before shipment to ensure quality meets requirements and that the finished product meets standards.
      Model:DIN 1587-1987

      Send Inquiry

      Product Description

      Keeping high efficiency hexagon domed cap nuts working well mostly means keeping their protective surface layer in good shape and making sure the threads don’t get damaged. You should check them regularly for signs the coating is wearing, chipping, or rust (red rust), especially if they’re in tough environments.

      Don’t use strong chemical cleaners,those can ruin the plating. In places with a lot of vibration, you might need to retighten them sometimes, following the maintenance schedule.

      Picking the right specs from the start,like the material, grade, and coating,for where they’ll be used is key. That’s how you get the long, reliable life you’d expect from these high strength domed cap nuts.

      Material grade and manufacturing process

      The high efficiency hexagon domed cap nuts comes from specific material grades and heat treatments. Common grades are ISO Property Class 8, 10, or 12.9 (for metric) and SAE Grade 5 or 8 (for imperial),these are like the high tensile steel types. These grades show the minimum tensile strength, like 800 MPa, 1000 MPa, or 1200 MPa for Class 8, 10, 12.9.

      High strength domed cap nuts get these qualities by choosing the right alloy and using controlled heat treatment. That way, they meet the strict mechanical requirements needed for critical uses.

      High Efficiency Hexagon Domed Cap Nuts parameter

      Mon
      M4 M5 M6 M8 M10
      P
      0.7 0.8 1 1|1.25 1|1.25|1.5
      dk max
      6.5 7.5 9.5 12.5 15
      e min
      7.66 8.79 11.05 14.38 17.77
      h max
      8 10 12 15 18
      h min
      7.64 9.64 11.57 14.57 17.57
      k max
      3.2 4 5 6.5 8
      k min
      2.9 3.7 4.7 6.14 7.64
      s max
      7 8 10 13 16
      s min
      6.78 7.78 9.78 12.73 15.73
      t min
      5.26 7.21 7.71 10.65 12.65
      t max
      5.74 7.79 8.29 11.35 13.35

      Bulk export packaging

      Q:How to package bulk exports to prevent damage and corrosion during transportation?

      A: For exports, our high efficiency hexagon domed cap nuts are packed securely in sturdy, sealed industrial buckets or heavy-duty cartons. We use VCI (Vapor Corrosion Inhibitor) packaging inside as standard,this helps keep them from rusting during long ocean trips and when stored in humid places. That way, these strong parts arrive in good shape, no rust. Stacking them on pallets makes handling safe too.
