These Flush Finishing Solid Flat Head Rivet come in a few different tough materials, and we pick the one that's right for the job. For instance, aluminum alloys are a common choice when you need something that's both lightweight and pretty resistant to rust.
If you need a lot of strength to hold things together, you'd look at steel options, like low carbon or stainless. Then there's copper, which is great for electrical work because it conducts so well, and Monel, which holds up better when there's moisture or chemicals around.
Basically, the stuff a Flush Finishing Solid flat head rivet is made from decides how strong it is, how much it weighs, and where you can use it. Picking the right material just makes sure your fastening job is solid and lasts a long time.
We put different finishes on Flush Finishing Solid Flat Head Rivet to help them last longer and work better in specific places. For example, zinc plating is a common one—it's really good at preventing rust and gives the rivet a silvery color.
If you're working with aluminum rivets, anodizing is a popular pick. This process makes the surface harder, lets you choose from a few colors, and still protects against corrosion. For tougher jobs, especially in aerospace, cadmium plating is another option used for rust prevention.
Of course, you can always go with a plain, unfinished rivet. This is the most basic and cost-effective choice if you don't need any special protection. The finish you select for a Flush Finishing Solid flat head rivet really comes down to making it more durable, helping it resist rust, and matching it to your project's needs.
How do I install a Flush Finishing Flush Finishing Solid Flat Head Rivet correctly?
To install a Flush Finishing Solid flat head rivet, place it in a pre-drilled hole and use a hammer with a bucking bar on the tail end. The Flush Finishing Solid flat head rivet forms a permanent bulge at the back for a strong, fixed joint.
| Unit of measurement(mm) | ||||||||||
| d | φ2 | φ2.5 | φ3 | Φ3.5 | φ4 | φ5 | φ6 | φ8 | φ10 | |
| d | Maximum value | 2.06 | 2.56 | 3.06 | 3.58 | 4.08 | 5.08 | 6.08 | 8.1 | 10.1 |
| Minimum value | 1.94 | 2.44 | 2.94 | 3.42 | 3.92 | 4.92 | 5.92 | 7.9 | 9.9 | |
| dk | Maximum value | 4.24 | 5.24 | 6.24 | 7.29 | 8.29 | 10.29 | 12.35 | 16.35 | 20.42 |
| Minimum value | 3.76 | 4.76 | 5.76 | 6.71 | 7.71 | 9.71 | 11.65 | 15.65 | 19.58 | |
| k | Maximum value | 1.2 | 1.4 | 1.6 | 1.8 | 2 | 2.2 | 2.6 | 3 | 3.44 |
| Minimum value | 0.8 | 1 | 1.2 | 1.4 | 1.6 | 1.8 | 2.2 | 2.6 | 2.96 | |
| r | Maximum value | 0.1 | 0.1 | 0.1 | 0.3 | 0.3 | 0.3 | 0.3 | 0.5 | 0.5 |
